EMCOD EGP750P12AC - 750W 12/24V AC - Indoor/Outdoor Dimmable Magnetic Power Supply - Powder Coated Black Steel

EMCOD EGP Indoor/Outdoor Dimmable Magnetic Power Supplies | EMCOD Lighting |
SKU: EGP750P12AC

  • $122.59
    Unit price per
  • Save $49.41



Conforms to UL STD. 2108
Certified to CSA
STD. C22.2 № 250.0,

Spec Sheet

Installation Instructions

Certification

Magnetic Outdoor
Black Powder Coated Steel Enclosure

Transformer

Temperature class B(130°C)
Two section bobbin completely separated primary and secondary windings
Input leads are 18AWG 600V
Output leads are 12AWG 300V
Leads max. operational temperature is 105°C
Thermal manually reset primary breaker 10A
per circuit

Housing

The actual transformer 750W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 6 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 9.4, W = 4.6, D = 4.1
Weight (LBs): 0.18

Electrical Parameters

Input Voltage: 120V 60Hz
Max. input current: 7A at full load
Output voltage without load: 12.4/ 24.8VAC
Output voltage fully loaded: 11.8/ 23.8VAC
Max. Total Wattage: 750W Max. per circuit:375W
Max. Output Current: 31/ 15.6A per circuit.
Efficiency: 93%
Load regulation: 0.05%

If you don't see the exact model number or color you are looking for, call our Internet Sales Department at 1-818-477-4017. We can get anything for you!
