EMCOD EGP200P12AC - 200W 12/24V AC - Indoor/Outdoor Dimmable Magnetic Power Supply - Powder Coated Black Steel

EMCOD EGP Indoor/Outdoor Dimmable Magnetic Power Supplies | EMCOD Lighting | Products |
SKU: EGP200P12AC

  • $68.39
    Unit price per
  • Save $27.61



Conforms to UL STD. 2108
Certified to CSA
STD. C22.2 № 250.0,

Spec Sheet

Installation Instructions

Certification

Magnetic Outdoor
Black Powder Coated Steel Enclosure

Transformer

Dimmable with compatible MLV, ELV, CL dimmers, please refer to list on
emcod.com
Temperature class B(130°C)
Two section bobbin completely separated primary and secondary windings
Input leads are 18AWG 600V
Output leads are 12AWG 300V
Leads max. operational temperature is 105°C
Thermal manually reset primary breaker 3A
per circuit

Housing

The actual transformer 200W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 6 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 8, W = 4.1, D = 3.1
Weight (LBs): 0.09

Electrical Parameters

Input Voltage: 120V 60Hz
Output voltage without load: 24.8VAC
Output voltage fully loaded: 23.8VAC
Max. Total Wattage: 200W Max. per circuit:100W
Max. Output Current: 10.4A per circuit.
Efficiency: 93%
