EMCOD MLE80-12DC-UD - 80W 12V DC- Dimmable Electronic LED Driver

EMCOD Lighting | EMCOD MLE-UD Series - Main-LED Electronic Universal Driver |
SKU: MLE80-12DC-UD

  • $128.29
    Unit price per
  • Save $51.71


E498696
Conforms to UL STD. 8750 and 1310
Certified to CSA
STD. C22.2 № 250.0
model MLE80-12DC-UD

Spec Sheet

Installation Instructions


Transformer

Dimmable with triac forward and reverse phase, 0/1-10V , resistor, PWM
Input leads are 18AWG 600V
Output leads are 16AWG 300V
Leads max. operational temperature is 105°C

Housing

The actual transformer 80W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 6 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 70°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 5.16, W = 7.73, D = 1.54
Weight (LBs): 3

Electrical Parameters

Input Voltage: 100-277V 50/60Hz
Max. input current: 0.8A at full load
Output voltage without load: 12.1VDC
Output voltage fully loaded: 12VDC
Max. Total Wattage: 80W
Max. Output Current: 6.6A
Efficiency: 87%
Load regulation: 1%
Ripple: 5%

If you don't see the exact model number or color you are looking for, call our Internet Sales Department at 1-818-477-4017. We can get anything for you!
