EMCOD - ML40S24AC Transformer - Magnetic LED Driver - 40W - 24VAC

EMCOD Lighting | EMCOD ML - MAG-LED Series | Products |
SKU: ML40S24AC

  • $49.89
    Unit price per
  • Save $20.11

Class 2 Magnetic LED AC Driver Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure

4008104
Conforms to UL STD. 1310
Certified to CSA
STD. C22.2 № 223
model EM35

Link to certification

Spec Sheet

Installation Instructions

Class 2 Magnetic LED AC Driver Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure

Transformer

Dimmable with compatible MLV, ELV, CL dimmers, please refer to list on
emcod.com
Temperature class B(130°C)
Input leads are 18AWG 600V
Output leads are 18AWG 300V
Leads max. operational temperature is 105°C
Thermal self reset primary breaker 0.8A
Thermal self reset secondary breaker 3A

Housing

The actual transformer 40W is encapsulated in the enclosure
The enclosure is Black Powder Coated Steel, NEMA 3R rated
Wiring compartment has 2 knockouts sizes for 3/8 inch screw cable
connectors
Enclosure Temperature does not exceed 75°C at 45°C ambient and fully
loaded
Dimensions (inch): H = 7, W = 2.11, D = 1.54
Weight (LBs): 2.1


Electrical Parameters

Input Voltage: 120V 60Hz
Max. input current: 0.4A at full load
Output voltage without load: 26.2VAC
Output voltage fully loaded: 23.6VAC
Max. Total Wattage: 40W
Max. Output Current: 1.7A
Efficiency: 85%

If you don't see the exact model number or color you are looking for, call our Internet Sales Department at 1-818-477-4017. We can get anything for you!
