Core Lighting RGB CT-400 WIFI RGB TOUCH SERIES WIFI CONTROLLER

Core Lighting - Architectural-Grade LED Lighting Solutions | Core Lighting Controllers & Decoders | Products |
SKU: RGB-CT400-WIFI

$209.40
Unit price per
Save $167.51

RGB CT-400 WIFI
RGB TOUCH SERIES WIFI CONTROLLER

The RGB CT-400 WiFi is a WiFi LED lighting control system. Various types of LED lighting products can be controlled by installing the APP on the user’s iOS or Android mobile device which supports WiFi connection.

■ Compatible with smart devices
■ Android and iOS Compatible
■ Optional RF Handheld Remote (Sold Separately)
■ 32 Fixed RGB Modes, 8 DIY Modes
■ Scene Mode: RGB 9 Modes, CT3 Modes

QUICK SPECS

INPUT VOLTAGE	12V-24V DC
MAX CURRENT LOAD	4A x 3CH 12A Max
MAX OUTPUT POWER	144W (12V) / 288W (24V)
OUTPUT CONTROL	Single Color, CT, RGB LEDs
CONTROL DISTANCE	up to 100 meters
RGB CHANGE MODE	32 Fixed, 8 DIY Modes
SCENE MODE	9 RGB, 3 CT Modes
OPERATING TEMP	-22ºC ~50ºC
OPERATING SYSTEM	iOS and ANDROID Compatible

RGBCT400WIFISPECV.2 (PDF)

BASIC WIRING GUIDE (PDF)

VOLTAGE DROP CHART (PDF)
