Lutron LMJ-16R-DV-B RF Relay Module with Softswitch

Lutron LMJ-16R-DV-B RF Relay Module with Softswitch

LUT-LMJ-16R-DV-B

Default Title

Available at 7950 Deering Ave

This item is available and ready.

Check availability at other stores

This product may have been updated and we're here to help.

If you were looking for this item, there may be updated or alternative versions available. Our team is happy to provide guidance, suggest compatible options, or answer any questions you have. We're just a call away.

Contact Us

These items don’t display pricing because they require a custom quote.

Product Information

Overview

The Lutron LMJ-16R-DV-B is a high-capacity RF relay module designed to control up to 16A of general-purpose loads. Utilizing Lutron's patented Softswitch technology, it eliminates relay contact arcing, significantly extending product life. This compact module integrates with RA2 Select, RadioRA 2, and HomeWorks systems via Clear Connect RF Technology, making it ideal for switching non-dimmable loads in residential or commercial settings. It installs easily into junction boxes and is rated for plenum applications.

Technical Specification

RF Relay Module with Softswitch; controls up to 16A of general-purpose loads. 120 V/277 V. Compatible with RA2 Select, RadioRA 2, and HomeWorks systems.

The RF relay module with Softswitch is a radio frequency (RF) device that uses Lutron patented Softswitch technology to control up to 16 A of general-purpose loads based on input from RA2 Select, RadioRA 2, and HomeWorks systems.

• Lutron patented Softswitch technology prevents arcing of relay contacts, extending product lifetime.

• Various operating voltages available—refer to Models chart below for details on voltage requirements.

• Capable of switching 16 A of general-purpose loads. • Utilizes Lutron Clear Connect RF technology—refer to Models chart below for frequency band data and Lutron system compatibility.

• Mounts to an electrical junction box through a 1/2 in (21 mm trade-size) knockout opening.

• Complies with requirements for use in a compartment handling environmental air (plenum) per NEC® 2011 300.22(C)(3) (LMJ- model only)

Documentation



Additional Information

  • Controls high-current loads such as outlets, fans, or commercial lighting circuits.
  • Softswitch technology eliminates arcing, extending relay life and reliability.
  • Installs into a standard junction box via a 1/2-inch trade-size knockout.
  • Designed for use in both residential and commercial plenum-rated environments.
  • Integrates with Lutron's wireless systems for seamless automation and energy management.
