GM Lighting LineDRIVE LD-MD-UNV60 60W 12VDC / 24VDC Magnetic LED Dimmable Power Supply

GM Lighting LineDRIVE LD-MD-UNV60 60W 12VDC / 24VDC Magnetic LED Dimmable Power Supply

$165.60 USD
$165.60 USD $331.20 USD

GMLighting-LD-MD-UNV60

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

Secure your shopping experience with various safe and trusted payment methods.

Will Call / Pick up

Have a question about this product, or need assistance with your order? Our team is here to provide quick, friendly support whenever you need it.

Contact Us

Product Information

Overview

The GM Lighting LineDRIVE LD-MD-UNV60 is a Class 2 rated magnetic LED dimmable power supply with universal input and selectable output. Designed for use with MLV dimmers, it supports both 12VDC and 24VDC LED loads and is housed in a low-profile, powder-coated steel enclosure. Ideal for vertical mounting, it features auto-reset protection and is ETL listed for both indoor and outdoor applications.

Technical Specification

Model
LD-MD-UNV60
Input Voltage
120V or 277V / 60Hz
Output Voltage
12VDC / 24VDC
Max Power
60W
Dimming
MLV Dimmable, down to 5%
Mounting Orientation
Vertical Only
Housing Material
Powder Coated Steel
Enclosure Rating
NEMA 3R (Outdoor Rated)
Protection
Auto Reset for Short Circuit and Over Voltage
Certifications
ETL Listed (Indoor & Outdoor)
Dimensions
8.86"L x 3.31"W x 2.89"H

Additional Information

  • Class 2 rated for safe LED lighting installations
  • Designed for compatibility with standard MLV dimmers
  • Includes 2 knockouts for easier installation
  • Ideal for use with GM Lighting LED products
  • Steel case offers durable protection in outdoor settings
