GM Lighting LineDRIVE LD-E-UNV96-24 96W 24VDC Electronic LED Non-Dimmable Power Supply

GM Lighting LineDRIVE LD-E-UNV96-24 96W 24VDC Electronic LED Non-Dimmable Power Supply

$154.80 USD
$154.80 USD $309.60 USD

GMLighting-LD-E-UNV96-24

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • Shop Pay
  • Visa

Secure your shopping experience with various safe and trusted payment methods.

Will Call / Pick up

Have a question about this product, or need assistance with your order? Our team is here to provide quick, friendly support whenever you need it.

Contact Us

Product Information

Overview

The GM Lighting LineDRIVE LD-E-UNV96-24 is a 96W Class 2 rated electronic LED power supply delivering 24VDC output. Designed for select LED fixtures that do not require dimming, it supports universal input voltages of 120V or 277V at 50/60Hz. The unit is housed in a low-profile powder-coated steel enclosure with four knock-outs for easy installation, and is especially suited for LTR-S RGBW tape lighting.

Technical Specification

Model
LD-E-UNV96-24
Input Voltage
120V or 277V ± 10%, 50/60Hz
Output Voltage
24VDC
Power Output
96W
Class Rating
Class 2
Dimensions
8.25" L x 4.10" W x 1.56" H
Dimming
Non-Dimmable
Enclosure
Powder coated steel with 4 knock-outs
Protection
Over voltage protection, Short circuit protection, Auto Reset
Certifications
FCC compliant, UL listed
IP Rating
IP20 for damp location
Voltage Tolerance
± 5% at full load

Additional Information

  • Suitable for select LED fixtures that do not require dimming
  • Powder coated steel enclosure provides durability and easy installation
  • Ideal for use with LTR-S RGBW tape lighting
