EMCOD - ML100S24DC Transformer - Magnetic LED Driver - 100W - 24VDC
EMCOD Lighting - LED drivers, Lighting and Transformers | EMCOD ML - MAG-LED Series | Products |SKU: ML100S24DC
Class 2 Magnetic Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure
Black Powder Coated Steel Enclosure
 4008104 |
Conforms to UL STD. 1310 |
| Certified to CSA STD. C22.2 № 223 |
|
| model EM100 | |
Electrical Parameters
| Input Voltage: | 120V 60Hz |
| Max. input current: | 1.1A at full load |
| Output voltage without load: | 27.2VDC |
| Output voltage fully loaded: | 23.5VDC |
| Max. Total Wattage: | 96W |
| Max. Output Current: | 4A |
| Efficiency: | 85% |
The unit has additional knockout on the back
